About the PEM Fuel Cell Powered Electric Bicycle
Aluminum Alloy Frame：
6.5% lighter than last generation but more robust;
Optimized structure：
New design ensures a more compact structure which integrates fuel cells, metal hydride tanks and bicycle together. The tanks are easily disassembled in new design；
Compliance with CE certificate：
The bicycle has achieved with CE certificate. The front light, rear light and spoke reflectors ensure you a safer ride at night. The fuel cells and metal hydride tanks also are in compliance with CE certificate；
Foldable structure：
The frame, handlebar and peddlers are foldable. It can save 12% space compared to the folded state of last generation fuel cell bicycle. It can be easier for transportation；
Better Transmission：
| 1. |
Driving distance: | ≥60 Km @ full fuel cell powered mode |
| 2. |
Driving Time: | ≥6 Hours @ Hybrid mode |
| 3. |
Max driving distance: | 100Km |
| 4. |
Max speed: | ≤25Km/h |
| 5. |
Power source: | 220 Watt PEM fuel cell |
| 6. |
Hydrogen consumption: | 3L/min |
| 7. |
Hydrogen storage: | 600L |
| 8. |
Dimensions (mm): | 1580×565×1075 |
| 9. |
Wheel:: | 20" |
| 10. |
Weight/Rated Loading: | 33Kg/75Kg |
| 11. |
Noise: | ≤60dB |
| 12. |
Motor type/power/voltage: | DC Brushless/180W/24V |
| 13. |
Low voltage Protection: | 21.5ħ0.5V |
| 14. |
Over-current protection: | 14Aħ1A |
